TYPE
Product family: Hood
Hood Type: Decorative wall hood
Hood width: 90 cm
Extraction: Extraction
Victoria Black - EAN code: 8017709211653
Victoria Cream - EAN code: 8017709211677
AESTHETICS
Colour: Black/Cream
Finishing: Glossy
Aesthetics: Victoria
Design: Chimney
Material: Painted material
Type of steel: Brushed
CONTROLS
Control setting: Control knobs
Control knobs: Victoria
No. of controls: 2
Controls colour: Steel effect
PROGRAMS / FUNCTIONS
Intensive/turbo setting: when extra fast extraction is required.
No. of speeds: 3
Intensive speed: Yes
TECHNICAL FEATURES
Filters: Model has filters to help remove grease from the steam emanating from the pans during cooking.
Lights: All cooker hoods feature lights to illuminate the cooking area or add to the ambience of the kitchen.
No. of lights: 2
Light type: LED
Light Power: 1 W
Light color temperature scale (°K): 3000 °K
Free outlet maximum capacity: 820 m³/h
Motor power: 275 W
No. of filters: 3
Anti-grease filters: Aluminium
Minimum distance from GAS hob: 750 mm
Vent outlet: 150 mm
Minimum distance from ELECTRIC hob: 650 mm
Non return valve: Yes
PERFORMANCE / ENERGY LABEL
Fluid Dynamic Efficiency class (FDEC): A
Grease Filtering Efficiency Class (GFEC): C
Lighting Efficiency Class (LEC): A
Annual Efficiency Consumption (AEChood): 59 kWh/a
Fluid Dynamic Efficiency (FDE): 30
Lighting Efficiency (LE): 102.3 lux/W
Grease Filtering Efficiency (GFE): 76.6 %
Air flow at minumum speed (Qmin): 334 m³/h
Air flow at maximum speed (Qmax): 567 m³/h
Air flow at boost speed (Qboost): 788 m³/h
Airbourne acouistical A-weighted sound Power Emission at minimum speed
(SPEmin): 49 dB(A)
Airborne acoustical A-weighted sound Power Emission at maximum speed
(SPEmax): 61 dB(A)
Airbourne acoustical A-weighted sound power emission at boost speed
(SPEboost): 69 dB(A)
Time increase factor (F): 1.00
Energy Efficiency Index: 52.4
Measured air flow rate at best efficiency point (Qbep): 438 m³/h
Measured air pressure at best efficiency point (Pbep): 434 Pa
Measured electric power input at best efficiency point (Wbep): 176 W
Nominal Power consumption of the light system (WL): 2 W
Average illumination of the light on the cooking surface (Emiddle): 225 lux
Sound power level at highest setting (Lwa): 61 dB(A)
ELECTRICAL CONNECTION
Electrical connection rating: 278 W
Voltage: 220-240 V
Frequency (Hz): 50-60 Hz
SPEED 1
Extraction rate IEC 61591: 334 m³/h
Noise level IEC 60704-2-13: 49 dB(A)
Power: 199 W
SPEED 2
Extraction rate IEC 61591: 439 m³/h
Noise level IEC 60704-2-13: 57 dB(A)
Power: 231 W
SPEED 3
Extraction rate IEC 61591: 567 m³/h
Noise level IEC 60704-2-13: 61 dB(A)
Power: 260 W
INTENSIVE SPEED
Extraction rate (IEC 61591): 788 m³/h
Noise level IEC 60704-2-13: 69 dB(A)
Power: 280 W
LOGISTIC INFORMATION
Dimensions of the product (mm): 740x895x530
Width: 895 mm
Depth (mm): 530 mm
Product Height (mm): 740 mm
