Product Features
Hood Type: Integrated (semi) hood
Hood width: 90 cm
Extraction: Extraction
Colour: Silver
Aesthetics: Universale
Design: Telescopic
Material: Stainless steel
Type of steel: Brushed
Programs/Functions
No. of speeds: 3
Speed 1
Extraction rate IEC 61591: 270 m³/h
Noise level IEC 60704-2-13: 53 dB(A)
Power: 160 W
Speed 2
Extraction rate IEC 61591: 360 m³/h
Noise level IEC 60704-2-13: 58 dB(A)
Power: 190 W
Speed 3
Extraction rate IEC 61591: 500 m³/h
Noise level IEC 60704-2-13: 66 dB(A)
Power: 230 W
Controls
Control setting: Slider
Technical Features
Filters: Model has filters to help remove grease from the steam emanating from the pans during cooking. Lights: All cooker hoods feature lights to illuminate the cooking area or add to the ambience of the kitchen.
No. of lights: 2
Light type: LED
Light Power: 4 W
Light color temperature scale (°K): 3000 °K
Free outlet maximum capacity: 520 m³/h
Motor power: 230 W
No. of filters: 2
Anti-grease filters: Aluminium
Minimum distance from GAS hob: 650 mm
Vent outlet: 120 mm
Minimum distance from ELECTRIC hob: 450 mm
Performance/Energy Label
Energy efficicency class ( EEC): D
Fluid Dynamic Efficiency class (FDEC): E
Grease Filtering Efficiency Class (GFEC): C
Lighting Efficiency Class (LEC): D
Annual Efficiency Consumption (AEChood): 127 kWh/a
Fluid Dynamic Efficiency (FDE): 9.8
Lighting Efficiency (LE): 16 lux/W
Grease Filtering Efficiency (GFE): 75.1 %
Air flow at minumum speed (Qmin): 270 m³/h
Air flow at maximum speed (Qmax): 500 m³/h
Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 53 dB(A)
Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 66 dB(A)
Time increase factor (F): 1.6
Energy Efficiency Index: 94.8
Measured air flow rate at best efficiency point (Qbep): 306 m³/h
Measured air pressure at best efficiency point (Pbep): 238 Pa
Measured electric power input at best efficiency point (Wbep): 207 W
Nominal Power consumption of the light system (WL): 8 W
Average illumination of the light on the cooking surface (Emiddle): 130 lux
Sound power level at highest setting (Lwa): 66 dB(A)
Electrical Connection
Electrical connection rating: 238 W
Voltage: 220-240 V
Frequency (Hz): 50 Hz
Power supply cable length: 1500 mm
Logistic Information
Dimensions of the product (mm): 420x898x270
Width: 898 mm
Depth (mm): 270 mm
Product Height (mm): 420 mm
